MUSIC HALL MMF-1.3 TURNTABLE | MUSIC HALL

$699.00

PHONO STAGE BUILT-IN
BELT-DRIVE TURNTABLE
VIBRATION DAMPING FEET

In stock

SKU: MUSIC HALL MMF-1.3 TURNTABLE Categories: , Tag:
SHARE

MMF-1.3 TURNTABLE

The music hall mmf-1.3 turntable sets a new benchmark for affordable audiophile turntables. With a built-in phono preamplifier and a quality, pre-mounted cartridge, the mmf-1.3 is everything you need to start listening to the vinyl right out of the box!

Focus On Components

Our new entry-level turntable provides a feature set that is unrivaled at its price. The construction of the mmf-1.3 has been simplified to focus on the critical components; the bearing, the motor, and the tonearm.

A Complete Package

A 3-speed belt driven turntable that comes complete with a tonearm, mounted cartridge, and built-in phono amp.

The included Audio Technica AT3600L cartridge has been precision aligned.

Brand

TURNTABLE SECTION

.

Motor

DC Motor

Driving Method

Belt Drive

Turntable Platter

Turntable Platter

Speeds

33 1/3, 45, And 78rpm

Wow And Flutter

Typical: Less Than 0.1% Wtd At 3khz Rms(Cd-4005)
Limit: Less Than 0.15% Wtd At 3khz Rms(Cd-4005)

S/N Ratio

More Than 62db (Din-B) (Ss-4242)

Speed Tolerance

3000hz +/-1%(Cd-4005)

CARTRIDGE SECTION

.

Stylus

Diamond Stylus

Height Of Arm Lifter

7.5mm (The Distance Between The Record And The Stylus When The Lifter
Lever Is Pulled Up)

Phono Output Level

1.5~3.6 Mv At 1khz 5cm/Sec (Cd-4005)

Line Output

90-216 Mv At 1khz 5cm/Sec (Cd-4005)

Riaa

20hz~20khz: +1/-3 Db

Cartridge

At3600l

Output Voltage

2.5mv +/- 3db At 1khz 3.54cm/Sec (At6606a)

Channel Separation

More Than 18db (At6606a)

Channel Balance

Within 2db At 1khz (At6606a)

Frequency Response

0 +/-3db At 10khz (At6606a)(Value At 10khz Based On Value At 1khz)

Tracking Force

3.5 ± 0.5 G

TONEARM SECTION

.

Type

Dynamic Balanced Straight Shaped W/Soft Damping Control

Effective Arm Length

221.5mm

Overhang

19mm

Offset Angle

25.61

Tracking Error Angle

3 Degree Or Less

Stylus Pressure Adjustment Method

Rotation Movability

Arm Lifter

Oil Damper Type

GENERAL

.

Power Supply

DC12V,2.0A Universal power supply

Consumption

4W

Dimensions

17.1(W) x 14.5(D) x 4.2(H) in.
435(W) x 367(D) x 106(H) mm

Weight

11lbs., 5Kg
