AMC: XP

XP – Stereo Pre-Amplifier | AMC

$899.00

BUY NOW →

Description

AMC Hi Fidelity electronic component manufacturer are responsible for most high end brands out there !
RIO Sound and Vision bring you their latest range with state of the art
build quality and a design reliability philosophy of 25years, their new XP Stereo Pre Amplifier will Deliver more detail and clarity when matched with a AMC High Power Amplifier. For the audio purists, you now have a solution which will baffle most audiophiles for the price and performance.

Features

Features Input “MIX” mode: Installed with mixing circuitry specially designed for Multimedia applications. End users can use the MIXING FEATURE to listen to music or program from Phonon/Aux, CD, Tuner or DVD, at the same time working on computer (connect sound card outputs to multimedia inputs). All will come out simultaneously from the same pair of speakers with the best possible sound quality.
Adjustable Input Sensitivities for all Inputs.
With True Balanced Outputs for PA applications or applications require balanced outputs.
Special designed passive Tone control circuit to give natural sound quality.
Uses audiophile grade components throughout, providing exceptional accuracy to tone control response.
Users can choices between 1U Rack mountable (XP) or not (XPi) for Various of applications.
High overload margin on tone control circuit by virtue of its topologies.
With Auto Power On/Off by Audio Signals, 3~30V AC/DC triggers or Constant.
Slick design and high quality controls makes this a stunning piece of hifi gear.

Brand

AMC

AMC Amplifiers - THE Power Amps

Designed with a 25 Year, operation with out fail philosophy, AMC amplifiers are High Quality Hi Fidelity Sound System components that can form part of any home or commercial sound system. This includes Multi-Room Electronic products. AMC amps provide the quality sound you want, without an inflated price tag.As a manufacturer of some of the worlds high end stereo components, you can be rest assured that AMC amps are built to last, look great and will perform at their best, long term.

Additional information

Price Bracket

600-1000

Line Level Inputs

(Aux, CD, Tuner, Multimedia, DVD and Tape In)

Input impedance( R and C)………………………………………………………………………….20Kohm/450pF
Input sensitivity 1KHz(ref.1V)…………………………………………………………………………………170mV
THD + SMPTE + IHK 1.M…………………………………………………………………………………….<0.003%
Frequency response 20Hz-20KHz…………………………………………………………………………+/-0.3dB
Frequency response -3dB………………………………………………………………………………5Hz/110KHz
Signal to noise ratio “A” WTD (ref..5.V)……………………………………………………………………>97 dB
Separation 20Hz-20KHz…………………………………………………………………………………………>80 dB
Maximum input level……………………………………………………………………………………………….>10 V
Line Level Outputs
Output impedance- Pre Out 1(unbalanced)…………………………………………………………..560 ohm
Pre Out 2(unbalanced)………………………………………………………………………………………560 ohm
Pre Out 3 XLR(unbalanced)………………………………………………………………………………….60 ohm
Pre Out 3 XRL(Balanced)……………………………………………………………………………………120 ohm
Output impedance – Phones………………………………………………………………………………..100 ohm
Maximum output level – Pre Out………………………………………………………………………………>8.5 V
Maximum output level – Phones (8 ohm load)………………………………………………………….>250 mV
Maximum output level – Phones open circuit………………………………………………………………….>9V
Tone Control
Bass at 100Hz…………………………………………………………………………………………….+8.5/-9.9 dB
Treble at 100KHz…………………………………………………………………………………………+7.5/-8.2 dB
Other
Dimensions (WxHxD)
XP (Rack Mount)…………………………………………………………………………………579×82(1U)x288mm
XPi (without Rack Mount)……………………………………………………………………..430×82(1U)x288mm
Net weight…………………………………………………………………………………………………………….4.2 Kg
Power……………………………………………………………………………………………………………….240 Volts
Warranty in Australia RBTB……………………………………………………………………………………3 Years
